HYFIX Units are Here: Here’s How to Get Your Hardware Ready

HYFIX Units are Here: Here’s How to Get Your Hardware Ready

The wait is over—HYFIX WB200 and MGW310 units officially started shipping on Wednesday, March 5! Whether you're a new Wingbits user or you've been following the updates closely, this is the moment many have been waiting for.

Right now, HYFIX is shipping mainly to distributors, including their regional branches in the U.S. From there, units will be sent out to end customers. The company expects to ship between 300 and 500 units per week as they scale production, though that number may shift as things settle.

If you've received your hardware (or you're just getting ready) this article will walk you through everything you need to know. We'll cover:

  • What’s included in your HYFIX package
  • How to set up the hardware correctly

Let’s get you up and running step by step.

What You’ll Need Before You Start

  • A Windows PC, Mac, or Ubuntu laptop
  • Access to your Wi-Fi network and router settings
  • The HYFIX device and included components (unboxed earlier)
  • A mobile app like Fing or Network Analyzer to help find your device’s IP address (Optional)

Note: Don’t use a mobile phone for setup—it’s not recommended now.

What’s in the Box?

Whether you ordered the WB200 or the MGW310, your HYFIX package comes with everything you need to get started with Wingbits. Here’s a quick look at what’s inside:

  1. WB200 Unit or MGW310: Your main HYFIX device.
  2. Power Cable with Built-In Ethernet: This connects your device to both power and internet via Ethernet. Antenna: Essential for receiving and sending signals.
  3. Mounting Rod: Used to elevate and position your antenna properly.
  4. Type C Power Plug Adapter: For regions using Type C power outlets.
  5. Type G Power Plug Adapter: For regions using Type G outlets (like the UK).
  6. Ethernet Extender: Helps reach your router if it's farther away.
  7. Mounting Brackets: Secure your antenna and hardware in place.
  8. AC Adapter: This attaches to the power cable to complete the setup.
Top-down view of the HYFIX WB200 box contents with numbered labels showing components: device (1), power and Ethernet cable (2), mounting rod (3), antenna (4), Type C plug (5), Type G plug (6), Ethernet extender (7), mounting brackets (8), and AC power adapter (9).

Full unboxing of the HYFIX WB200.

Setting Up Your HYFIX Hardware

Here’s how to get your HYFIX WB200 or MGW310 up and running:

Step 1: Connect the Antenna

  1. Take the HYFIX device and remove the protective cap from the antenna port on top.
  2. Grab the ADS-B antenna and push its connector onto the port until it fits snugly.
  3. Twist the antenna’s metal collar to tighten it. This ensures a secure and weather-resistant connection.
Close-up of a hand attaching the ADS-B antenna connector to the top of the HYFIX device, showing the screw-on collar mechanism.
Connecting the ADS-B antenna to the HYFIX device.

Step 2: Plug In the Power and Ethernet Cable

  1. Use the right-angle end of the long black cable (the one with both power and Ethernet combined).
  2. Line up the notch on the cable with the one on the port on the side of the device.
  3. Push the connector firmly, then twist the collar to lock it in.
Close-up of a person holding the molded right-angle connector of the HYFIX power and Ethernet cable, showing how it lines up with the device’s port.Combined power and Ethernet cable.

Tip: This combined cable helps keep the setup clean and protects the connection from weather.

Step 3: Power It On

Plug the AC adapter into a wall socket. Connect the round DC jack end to the end of the combined cable. The device should power automatically—you’ll notice some LEDs flashing on the side.

Close-up of a HYFIX power adapter with a Type G plug and a connected DC jack, ready to be inserted into the device’s cable.Plug the DC jack from the AC adapter.

Step 4: Choose Ethernet or Wi-Fi

Option A: Using Wi-Fi

  1. Don’t plug in the Ethernet cable if you're using Wi-Fi only.
  2. Wait for the device to boot up. Then, on your phone or computer, connect to the Wi-Fi network, like WB200_XXXXXX or MGW310_XXXXXX.
  3. Use the serial number (SN/G) printed on the device as the Wi-Fi password.
Screenshot showing a Wi-Fi network login prompt for “MGW310_53C9B6” with the serial number entered as the WPA2 password.

Connect to the MGW310 or WB200 Wi-Fi access point.

  1. Open a browser and go to http://192.168.10.1.
  2. Enter your Wi-Fi name (SSID) and password to connect the device to your home network.
Screenshot of the HYFIX device setup page showing fields to enter Wi-Fi SSID, password, and Miner Key for MGW310 or WB200.Device setup page for the MGW310 and WB200.

If you’re using an MGW310, you must create a Miner Key (12–18 letters and numbers, no symbols). Save this, as you’ll need it later when onboarding to GEODNET.

Screenshot showing a progress bar labeled “Applying settings...” at 70%, with a message about automatic redirection and a fallback link.Applying settings—please wait for the setup to complete.

Option B: Using Ethernet

Just plug the Ethernet end of the cable into your router or switch. The device will connect automatically.

Step 5: Find Your Device’s IP Address

To access your HYFIX device’s web dashboard:

  1. Log into your router’s admin panel or use an app like Fing or Network Analyzer.
  2. Look for a device labeled something like WB200_XXXXXX or MGW310_XXXXXX.
  3. Copy the IP address listed.

Some systems support browsing to http://wb200_xxxxxx.local, but using the IP is more reliable.

Screenshot of a router web dashboard displaying a connected HYFIX device with its network name and IP address.

HYFIX device listed in the router dashboard with its assigned IP address.

Tap on the device name in your router or app, and you’ll see the IP address listed there.

Screenshot from a mobile router app showing the connected HYFIX device's name, IP address, and network info.
Viewing HYFIX device details in a router app to locate its IP address.
Screenshot showing HYFIX device network details such as IP address, MAC address, device model, name, and type in the router’s web interface.

HYFIX device details shown in the router dashboard.

Step 6: Log In to the Device

  1. Paste the IP address into your browser.
  2. On the login screen, enter the GEODNET serial number (SN/G) as the password.
Screenshot of the HYFIX device web UI login page prompting for a password, with fields to enter credentials for WB200 or MGW310.

Login screen for the HYFIX WB200 and MGW310 devices.

From here, you can:

  • Reconnect to Wi-Fi
  • Change or update the Miner Key (MGW310 only)
  • Reboot the device
  • View device status and logs

WB200 and MGW310 devices have slightly different layouts, but the core features are the same. The MGW310 includes a few extra settings for GEODNET mining.

Screenshot of the MGW310 status interface displaying connection details, system stats, and menu options.

MGW310 device status page

Screenshot of the HYFIX WB200 interface displaying device status details like Wi-Fi mode, IP address, mining status, uptime, and network health.

WB200 device status page

Step 7: Mount the Device

Your package includes:

  • A mounting rod
HYFIX device next to a threaded mounting rod and two metal wall clips with screws, laid out on a wooden surface.

Threaded rod and mounting clips.

  • Clips and screws to secure the rod
  • A 5/8"-11 threaded connector on the device’s bottom

To mount:

Screw the rod into the base of the device.

Close-up of the HYFIX device with the threaded metal rod screwed into its base, secured with a washer and nut.

 Threaded mounting rod securely attached to the bottom of the HYFIX device.

Use the included clips and screws to attach the rod to a post or wall.

Side view of the HYFIX device with a threaded rod attached to its base and secured using three mounting clips along the rod.

 Fully assembled HYFIX unit with threaded rod mounted using wall clips.

Make sure it’s vertical and tightly secured.

HYFIX WB200 device installed on a vertical wall with the mounting rod held in place by metal clips and screws.

 HYFIX WB200 securely mounted to a wall using the threaded rod and clip system.

A clear sky view helps performance, so mount it outdoors or near a window if possible.

Step 8: Change or Disable Wi-Fi (If Needed)

If you ever need to switch networks or disconnect Wi-Fi:

  1. Click the “Settings” menu
  2. Choose “Network”
  3. Update your SSID and Wi-Fi password
  4. Click “Connect WiFi” to save the new settings

To turn off Wi-Fi and return to Access Point (AP) mode, click “Go to AP Mode” at the bottom of the Network page

This is helpful if you’re troubleshooting or switching from Wi-Fi to Ethernet.

Screenshot of the HYFIX network settings page showing options to input Wi-Fi credentials, disconnect, or enable AP mode.

Network settings page where you can connect to Wi-Fi, switch to AP mode, or manage device network preferences.

Step 10: Update Your Miner Key (MGW310 Only)

If you need to create or change your Miner Key for GEODNET:

  1. Click “Settings”
  2. Then go to “Miner”
  3. Enter your new Miner Key (must be 12–18 characters, letters and numbers only—no special symbols)
  4. Click “Save”
  5. Reboot the device or unplug/replug to apply the change

Tip: You can also reboot the device or disable the graphing tools (graphs1090/tar1090) from this same page.

Screenshot of the MGW310 Miner Settings interface showing fields for editing the Miner Key and options to reboot or disable data graphs.

MGW310 Miner Settings page

Understanding LED Lights

The device has three status LEDs:

  • Power: Confirms the device is on
  • PPS: Sync status
  • Status: Shows network or mining activity

Here’s what each LED means in more detail:

Visual chart showing LED behaviors for HYFIX devices: solid, flashing, or off states for POWER (red), PPS (green), and Status (yellow) indicators.

HYFIX LED status guide for POWER, PPS, and Status indicators.

Table showing various LED states for HYFIX devices, including red POWER, green PPS, and yellow Status lights, with descriptions for each condition like system loading, GPS validity, and network connectivity.

 Explanation of LED patterns for HYFIX devices

You’ve got your HYFIX hardware set up, connected, and ready to go. From here, you can onboard to Wingbits and start contributing to the network. If you're using an MGW310, you can also link it to GEODNET and begin earning.

FAQs

Do the devices come with a warranty?

Yes, HYFIX provides a 12-month manufacturer warranty. For specific details, contact HYFIX using the contact info on the Wingbits Approved Distributors page.

What are the device dimensions and weight?

Dimensions: 94.17 × 159.64 × 159.64 mm (antenna not included)

WB200 Weight: ~915g (1015g with antenna)

MGW310 Weight: ~925g (1025g with antenna)

What is the temperature rating?

Storage: -40°C to +85°C

Operating: -20°C to +70°C

How much power do the devices use?

WB200: 5 watts

MGW310: 5.5 watts
