This will show you how to setup and solo mine BTC on your Jingle Miner! While solo mining you earn all(~3 BTC) or nothing. You can check your mining odds here: Moken Asics Calculator
1) Connect the antenna to the Jingle miner.
2) Connect the power supply adapter of your region to the power supply.
3) Connect the power supply to the Jingle Miner.
4) Plug the power supply into the wall.
5) On the Jingle miner you will first see this screen. It's trying to connect to a non existing wifi network. After it fails in about 20 seconds the setup screen will pop up.
6) When you see the last screen above, open your phone wifi networks and connect to the jingle miner.
7) You should be at the captive portal, press the hamburger menu.
8) Tap on settings.
9) Fill in your wifi information. Then scroll to the bottom and press Save then Restart.
10) When the device boots up it will connect to your wifi and display its IP address. Visit that IP in your browser.
11) Click on the settings cog. Then scroll down a bit till you see the pool settings.
12) To keep this simple, we are going to use SoloCK pool. There are a bunch of pools out there you can choose from that have different features and fees. This is the simplest because it doesn't require an account.
In the primary stratum pool set the following:
Stratum host: solo.ckpool.org
Stratum port: 3333
Password: x (The password is really just x)
Do the same for the fallback stratum pool too.
13) We didn't fill in the stratum user yet. The username is like this:
<your bitcoin wallet address>.<devicename>
For example:
bc1pfng0esd5eg2qafmfa0.jinglesololite
We choose to name it jinglesololite, because this unit is a Jingle Miner Solo Lite edition. You can name it what ever you wish to help you keep track of your devices.
The bitcoin wallet address is very important that its yours. Because if you Mine a block the bitcoins will be sent to that address! If you don't have a bitcoin wallet, you can download Phantom.
So fill in the stratum user and also for the fallback stratum pool too.
14) Scroll down and Press Save then Restart.
15) The setup is done. You can view statistics about your mining progress here: https://solostats.ckpool.org/
Paste your bitcoin wallet address in the top right search box.
If you mine a bitcoin block the coins will be sent to your wallet. So be sure to check every once in awhile in your wallet app!
