This guide will show you how to setup the computer portion of the WB200 and MGW310. Both of them follow the same initial steps. So you can start at step 1 for both devices.
1) Unboxing the unit and connect the antenna to the unit. Do not rip off the rubber cap.
2) Connect the units power cord. It only goes in one way. So be careful not to bend the pins! Tighten the faster finger tight. Do not use a wrench!
3) Connect the power adapter to the power cord then into the wall. Optionally connect the ethernet cable. We will continue this setup using WiFi.
4) On a computer connect to the units WiFi network. On the unit you will find a sticker with a serial number (SN/G). The first line will be your WiFi password. It will be different for every unit. In our case it's: 9CB8B4F099BC.
5) Open a internet browser and visit http://192.168.10.1/ you will see this page.
6) For the first box enter your wifi network name at the location you are installing at. Followed by the WiFi password of that network. For miner key you create your own password here. When you press save you will be disconnected from the Wingbits unit and re connected to your main wifi network.
7) Head over to http://wingbits.com/dashboard and login. Click my stations at the top.
8) Because you are supposed to have reserved a Hex already we are assuming you did that already. Select your stations that have been reserved, then press Link HYFIX.
9) This modal will pop up asking for details.
10) Station, name it if you wish. Device serial. This is the second line on the device sticker, in our case: 0123C86A880A7AB5EE. The Device Secret is at the bottom of the device. In our example: BECC5B. Then press Link Device.
11) You are now done the computer setup for the WB200 unit. Folks with the MGW310 still have a couple more steps to active the Geodnet portion of earnings. Head over to http://console.geodnet.com/ in a browser. Login, or if you don't have an account create one.
12) Press Add miner.
13) We will fill in the information.
Miner SN is the miners serial number:
Nick name you can set to whatever.
Miner key is the password we created in step 6.
Enter the verification code and press add.
14) Scroll horizontal on the newly added miner and click on Token Issuance toggle. This will make it so tokens get sent to our wallet.
15) Finally click on the wallet tab at the top and fill in your wallet information so the tokens know where to get sent to. You are now done the MGW310 computer setup.
While we are done the computer setup for both units. You will now need to install the units outdoors. There are plenty of guides on this. If you have install questions head over to the Moken Forums or into the Moken / HD Discord for help!
